| Engine | Four-cylinder, "L" head. Bore 3-3/8", stroke 4-1/4". Piston displacement 152 cubic inches. Actual brake horsepower 36 at 2400 r.p.m.; S.A.E. rating 18.2. Nelson Bohnalite alloy pistons. Camshaft driven by Morse silent chain chain drive – adjustable. 3-bearing crankshaft. Cylinder cast en-bloc – detachable head. |
|---|
| Engine lubrication | Full force feed lubrication. |
|---|
| Cooling system | Centrifugal water pump; honeycomb type radiator. Water capacity – 6-1/2 quarts. 16 inch, 4-blade fan; flat endless belt. |
|---|
| Fuel supply | Vacuum feed Stewart. Fuel tank mounted on rear of chassis. |
|---|
| Clutch | Single dry plate – smooth positive. Enclosed in flywheel – removable without disturbing engine or transmission. Flywheel covered with metal shield. |
|---|
| Transmission | 3 speed – selective sliding. Ball bearing main shaft. Alloy steel hardened gears. Drive from motor to transmission is through special Spicer metal and rubber double universal joint eliminating shocks.; Gear ratios: First speed, 3.32:1; Second speed: 1.77:1; Third speed: 1.00:1 |
|---|
| Front axle | Drop type, high grade forged I-beam. Center point steering. Ball type thrust bearings on knuckles. |
|---|
| Rear axle | Semi-floating; Split housing type; 4.44 to 1 ratio. |
|---|
| Final gear ratios | 1st speed: 14.74 to 1; 2nd speed: 7.86 to 1; 3rd speed 4.44 to 1; reverse 18.6 to 1. |
|---|
| Brakes | Two shoe 11 inch Bendix Duo-servo brakes – all brakes adjusting to give same braking – no equalizers. |
|---|
| Chassis lubrication | Alemite high pressure. |
|---|
| Springs | Semi-elliptic; Front – length 36"; width 1-3/4"; Rear – length 54"; width 1-3/4" |
|---|
| Steering gear | Worm and Wheel Adjustable. 11 to 1 ratio. 17 inch steering wheel – flush type. |
|---|
| Wheels | 19 inch wood wheels, 4 inch rims. |
|---|
| Tires | 29×5.00 Balloon tires; 28×4.75 on convertible roadster. |
|---|
| Wheelbase | 107 inches |
|---|
| Electrical system | Auto-lite ignition. |
|---|
| Equipment | Front and rear fenders, wood running boards, metal side aprons, side tire carrier, stop light, spare rim, tool kit, gasoline gauge, gasoline filter. |
|---|
| General dimensions and length | Tread standard 56 inches. Turning radius approximately 2 feet. |
|---|
