| Engine | Six-cylinder "L" Head, 3¼" bore by 4" stroke. Displacement 199 cubic inches. Brake horsepower, 57 at 2800 r.p.m. Pistons, isometric type, made of Bohnalite with invar struts; crankcase vapor remover. |
|---|
| Crankshaft | Drop forged, heat treated, weight 48 pounds. 4 main bearings.. |
|---|
| Engine lubrication | Full force feed system; oil filter; gear type pump forces oil to all crankshaft and camshaft bearings, and timing chain; oil spray for wrist pins, cylinder walls and valve mechanism. |
|---|
| Cooling system | Centrifugal water pump; thermostat control of temperature; four blade fan driven by V belt from crankshaft; water capacity of cylinder jacket and radiator 14 quarts. |
|---|
| Gasoline supply | 14 gallon fuel tank; diaphragm pump, fuel feed. |
|---|
| Carburetor | 1¼" carburetor equipped with accelerating device and economizer. |
|---|
| Clutch | 10" single dry disc. |
|---|
| Transmission | 4-Forward-Speed; roller bearing countershaft; power take-off opening on both right and left sides; gear ratios: first, 6.417:1; second, 3.86:1; third, 1.797:1; fourth, 1:1. |
|---|
| Springs | Front – Overslung, semi-elliptic; length 36¾", width 2;"; self-adjusting spring shackles. Rear – Overslung, semi-elliptic; length 50"; width, 2½", heavy forged spring shackles. (Auxiliary spring equipment available, adding 33% to load capacity.) |
|---|
| Front axle | Reverse Elliott type; drop forged, heat-treated I-beam. |
|---|
| Rear axle | Semi-floating; spiral bevel driven; straddle mounted pinion; ratio 5.375:1. |
|---|
| Brakes | Steeldraulic, four-wheel brakes; hand brake operates on propeller shaft drum. |
|---|
| Chassis lubrication | Pressure gun. |
|---|
| Wheels | Hollow steel spoke type, latest approved design; special provision for dual tires.. |
|---|
| Tires | Front, 5.50:20, 6-ply balloons. Rear, 32×6, 8-ply, high pressure. (Note – 32×6 spare may be used on front wheels in emergency.) |
|---|
| Wheelbase | 134 inches |
|---|
| Starting, lighting, ignition | 6-volt, belt driven generator; manual and automatic spark control. |
|---|
| Standard equipment | Front bumper; head, tail and stop lights; front and rear fenders; full running board; spare rim; tool kit; grease gun; and jack. Coincidental ignition switch and coil lock; ammeter; electric gasoline gauge; electric engine temperature indicator; oil pressure gauge and speedometer. |
|---|
