| Engine | Six cylinders, "L" head type; 48 horsepower at 2,400 r.p.m.; bore, 3-18"; stroke 4-1/4"; 195.6 cubic inch displacement. |
|---|
| Cylinders | Cast en-bloc with upper half of crankcase. |
|---|
| Valves | 1-1/2" diameter, 5/16" lift. |
|---|
| Pistons | Three rings, 3/16" wide, all above piston pin. |
|---|
| Connecting rods | 8-1/4" center to center; material is drop-forged steel; bearing is cast in rod; diameter, 2"; width, 1-1/2"; |
|---|
| Crankshaft | Four-bearing; front, 2" diameter and 1-1/2" long; both center bearings, 2" diameter and 1-1/4" long; rear bearing, 2" diameter and 2-1/2" long; all bearings easily accessible by removing oil pan without disturbing any other parts. |
|---|
| Camshaft | Four-bearing; carbon steel; case-hardened and ground. |
|---|
| Engine lubrication | Force feed gear type oil pump; camshaft drilled and oil is forced to camshaft bearings through case to main crankshaft bearings and to connecting rod bearings. |
|---|
| Cooling system | Fedders radiator; honeycomb type, 16" four-blade fan; water capacity of cooling system is 12 quarts. |
|---|
| Timing gear drive | Morse silent chain; simple adjustment. |
|---|
| Carburetor | 1 inch Tillotson carburetor; combination intake and exhaust manifold with hot spot; located on left side of engine and has carburetor attached. |
|---|
| Clutch | Single plate, dry type; enclosed in flywheel; easily adjusted or removed without disturbing engine or transmission. |
|---|
| Transmission | Warner standard selective type; three speeds forward and one reverse, located amidship of car. |
|---|
| Electric system | Auto-Lite starting motor, generator, coil and distributor; U.S.L. battery, 92 amp. hours. |
|---|
| Drive | Left-hand drive, with spark and throttle levers mounted on steering wheel; ignition and lighting switch mounted on instrument board. |
|---|
| Front axle | Adams; reverse Elliott type, inclined king pins, tapered roller hub bearings. |
|---|
| Rear axle | Adams; semi-floating type; spiral bevel pinion and ring gear; ratio, 4-7/9 to 1. |
|---|
| Brakes | Double-shoe type on front and rear wheels; operated from foot pedal; emergency connection to hand brake lever. |
|---|
| Springs | Semi-floating type; front, 35" long; rear, 50-1/2" long; spring bolts, 9/16" diameter; front, seven leaves; rear, seven leaves; springs are 2" wide. |
|---|
| Tires | 30" x 3½" straight sided cord; demountable; spare rim furnished. |
|---|
| Chassis lubrication | Alemite system. |
|---|
| Steering gear | Warner worm and gear type; ball thrust bearings with adjustment to take up wear; 16" steering wheel; horn button mounted on steering wheel. |
|---|
| Frame | Pressed steel with 4-1/2" channel, 5/32" thick; five cross members and four-point motor suspension. |
|---|
| Gasoline supply | Stewart vacuum feed is used; gasoline tank located at rear of frame and has a capacity of 12 gallons. |
|---|
| Wheelbase | 115 inches |
|---|
| Headlamps | Drum-type, nickel-plated rim; equipped with Flare Lite reflector. |
|---|
| Horn | Motor-driven. |
|---|
